Antifouling screen

The anti pollution screen is an economical and general-purpose oil intercepting belt, which is applicable to the interception and control of oil spills and other floating objects in the calm waters near the shore. It can be used for emergency storage, hazard prevention drill, and interception and deployment of clean-up operations. It has been widely used in inland pollutant discharge outlets, water intakes, rivers, harbors, lakes and offshore oil drilling platforms. The universal horizontal horizontal foam solid float high-strength double-sided coated plastic cloth oil barrier has the advantages of wind wave resistance and oil retention ability, firmness, convenient use, easy cleaning and maintenance, etc. the outstanding advantage is that there is no water in the oil barrier, so the cloth is light to put in and recover, suitable for manual placement, long-term placement in water and emergency placement.

Cleaning and maintenance of anti fouling screen: when the oil retaining belt is stained with oil, it shall be timely cleaned with a cleaning machine or cotton yarn, oil remover, brush, etc. the oil retaining belt stored in the water for a long time shall be regularly cleaned of the attachments on the oil retaining belt and regularly received for shore inspection, and the missing parts shall be replaced. Different oil barriers shall be spliced according to the method recommended by the manufacturer. The worn and scraped parts of the oil barrier can be repaired with oil barrier cloth and adhesive.

Over the years, our company has carried out continuous product upgrading, R & D and design of anti fouling screens according to different projects and water conditions. The skirt of the anti fouling screen can be made of different materials according to the user's water quality and hydrological conditions and treatment requirements.

1. Control the diffusion of sediment in the maritime construction site

2. Prevent oil spill pollution

3. Effectively protect the riverbank and coastal ecological environment

4. Simple and convenient construction

Parameter

Technical parameters of antifouling screen

SPECIFICATIONS OF GEO SILT PROTECTOR

Physical indexCompanyTest methodSL15SL20SL25SL30
Massg/m²ASTM D 52615207009001100
Tensile strengthNASTM D 46323700510062007400
Tensile strengthKN/MASTM D 4595150200250300
Elongation at break%ASTM D 463215-3015-3015-3015-30
PermeabilitySˉ¹ASTM D 44910.01-0.8
Geotextile material
ASTM D 276Polyester
PVC buoyDiameter260mm, 280mm, 300mm, 400mm

Material descriptionThe surface of the floating PVC buoy is covered with colored PVC, and its surface contains corrosion-resistant and long-term active substances. The large buoy is more obvious and stable in the process of use. It is mainly used in oil wells and plugged pollution areas.
Application Scope
